Construction Equipment Mechanical Design Services

Industry

General Engineering

Services

Mechanical Design, FEA, CAD

Location

The challenge

DOCAN have been supporting Webster Technologies in the design and development of their ROCKHIT and ROCKWHEEL equipment.

image: webstertechnologies.co.uk

The DOCAN solution

We have employed a range of different services to support various aspects of this project, which have included:

Optioneering of design concepts
Hand calculation for sizing of components, stress calculation, hertzian stress calcs., bearing selection, etc.
Conducting FEA using the ABAQUS/CAE FEA package, including implicit and explicit methods with linear elastic and hyper-elastic materials, to model the equipment during use and identify load cases to be used as a basis for design.

The outcome

"We have been working on a very challenging design, involving high speed impact, for a number of years now. I wish we had engaged with DOCAN from the start as it would have saved us time and money. Their engineering knowledge and FEA software has proved to be a huge asset to the project. I can now see that if I had worked with this company in the past I would have released products much faster."

Ian Webster

Chairman, Webster Technologies

Project summary

Task	Application	DOCAN Expertise	Hand calculations	ABAQUS implicit/explicit	3D modelling
Mechanical systems design	Fabricated structures
	Bearings
	Rubbers
	Hydraulics
	Bolted connections
