Dynamic Pipe Stress Analysis
PSA, Flownex, Transient, Dynamic
UK - England
A silencer for a high-pressure steam vent line required validation in the event of a pressure safety valve (PSV) opening on a UK power station.
The client required to understand the dynamic piping loads that would be present on the vent line during the PSV opening to verify the integrity of the line, to then be able to verify if the pipe remained design code compliant during the PSV event.
The DOCAN solution
We used a combination of 1D Thermo-fluids network analysis and Pipe Stress Analysis (PSA) to model and determine the transient loads that would be generated due to steam flow within the pipe and the corresponding dynamic response of the pipe, the stresses generated on the pipe, and the loads transferred to the supports.
We worked with the client to supply them the necessary information to confirm the integrity of their system.
|Task||Application||DOCAN Design Expertise||Flownex||PSA||ROHR2|
|Piping system modelling||Information review|
|Thermofluid network building||Model import and export features|
|Flow rates & boundary conditions|
|Piping Analysis||Transient Scenario|
